Industrial ruggedized all-in-one machine series

Rugged all-in-one machine series

MAIN FEATURES:

1) Inter, AMD processors

2)Supports Linux and Windows operating systems

3) Fast computing speed, low heat generation, and low power consumption

4) User's application software and product hardware can be customized

PRODUCT MODEL:

specifications	12.1″Integrated machine	15″Integrated machine	17″Integrated machine	20.1″Integrated machine
screen size	12.1inch	15inch	17inch	20.1inch
resolution	800*600 (touch）	1024*768 (touch）	1280*1024 (touch）	1600*1200(touch）
brightness	300cd/m2	300cd/m2	300cd/m2	300cd/m2
CPU	dominant frequency 1.91GHZ,GHz	dominant frequency 1.91GHZ,GHz	dominant frequency 1.91GHZ/2.4GHZ，GHz	dominant frequency 1.91GHZ/2.4GHZ，GHz
CPU	dominant frequency 1.91GHZ,GHz	dominant frequency 1.91GHZ,GHz	dominant frequency 1.91GHZ/2.4GHZ，GHz	dominant frequency 1.91GHZ/2.4GHZ，GHz
Memory	4GB～8GB	4GB～8GB	4GB～8GB	4GB～8GB
Electronic hard drive	500GB～2TB	500GB～2TB	500GB～2TB	500GB～2TB
USB port	4port	4port	4port	4port
CAN port	2port	2port	2port	2port
Network port	2port	2port	4port	4port
Serial port	4port	4port	4port	4port
External display port	VGA	VGA/HDMI	VGA/HDMI	VGA/HDMI
power waste	≦20W	≦30W	≦40W	≦50W
Power Supply	AC 110V+10%/220C±10% / DC 9～36V
operating system	support:Windows、Linux

Environmental Indicators:

Working temperature:	-40℃-+60℃;-20℃-+55℃;0℃-+50℃;
Storage temperature:	-40 ℃~+70 ℃
Environmental adaptability:	MIL-STD-810
Electromagnetic compatibility:	MIL-STD-461
